Mobile Tank System QUADRO-DV - for Diesel - 330 Liters without Accessories by Rietberg 🚛
✅ Mobile Tank System QUADRO-DV – 330 or 450 Liter Diesel Tank by Rietberg
Double-walled. Extremely robust. Suitable for Diesel, HVO & E-Fuels – mobile, safe, and compliant with regulations.
The QUADRO-DV tank systems are the optimal solution for on-site mobile fuel supply. Ideally suited for use in construction yards, construction sites, forestry work, agriculture, golf courses, and landfills, they offer permanent UN approval (IBC) and a nationwide valid storage approval, ensuring their legal use. Whether for Diesel, HVO, or E-Fuels – the QUADRO-DV tanks are future-proof and optimally prepared for modern fuels.
🛠️ Your Benefits at a Glance:
- ✅ UN approval as IBC (ADR, RID, ADN, IMDG Code) – permanent
- ✅ General building authority approval as storage container
- ✅ Double-walled steel container – no catch basin required
- ✅ Suitable for outdoor use & water protection areas
- ✅ No hazardous goods driving license & no vehicle marking required
- ✅ Stackable up to three times, forklift & crane compatible
- ✅ Extremely robust thanks to galvanized steel with longitudinal ribs
- ✅ Operable even when secured
⚙️ Technical Features:
- Double-walled with permanent, energy-independent vacuum leak monitoring
- Suction line with shut-off ball valve
- Nozzle holder with return shut-off for clean refueling
- Mechanical fill level indicator
- Central fitting block including safety valve and optional limit sensor
- Lateral conduit for hose lines & power connections
- Lockable lid with gas pressure springs & 3-point locking system
- Closed foot construction for safe forklift transport
- 4 crane lugs according to DGUV 209-013
🌱 For Modern Fuels:
- ✔ Suitable for Diesel, HVO (Hydrotreated Vegetable Oil) & E-Fuels
- ✔ Sustainable & future-ready
📐 Available Models (Standard Version):
QUADRO-DV 330: Capacity: 330 L, Dimensions: 1200 x 800 x 807 mm, Weight: 219 kg.
QUADRO-DV 450: Capacity: 450 L, Dimensions: 1200 x 800 x 942 mm, Weight: 238 kg.
🔧 Complete Packages with Pump Technology:
QUADRO-DV 330-12/24:
- Motor pump R50 (12/24 V DC)
- 6 m hose assembly + swivel joint
- Connection cable with battery clamps
- Automatic nozzle
- Counter PZ300
- Flow rate: 35/70 l/min
QUADRO-DV 330-230:
- Motor pump R50 (230 V AC)
- 6 m hose assembly + swivel joint
- Connection cable with Schuko plug
- Automatic nozzle
- Counter PZ300
- Flow rate: 56 l/min
QUADRO-DV 450-12/24 and 450-230 are equipped identically as above, adjusted for tank size.
💡 Conclusion:
The Rietberg QUADRO-DV tank system represents mobile safety, efficiency, and sustainability. Whether as a standard model or a complete system with pump technology – it supplies fuel wherever it is needed.
