Product comparison · Compact & large-capacity systems

Farm Fuel Stations 1,000 – 10,000 Litres compared side by side

Compare HDPE/sheet-steel compact units and PE large-capacity systems from Roth, Schütz, Dehoust, Swimer, Kingspan, Pressol and Seppeler. Every feature at a glance – pump output, flow meter, fuel terminal, wall construction and approval.

✅ 27 models compared ✅ 32 – 72 l/min ✅ 1,000 to 10,000 litres ✅ DIBt-approved · double-walled

HDPE / sheet steel

Compact combination of an HDPE inner tank and a sheet-steel outer shell. Up to 2,000 litres, double-walled, for farm and agricultural use. Models from Roth, Schütz and Dehoust.

PE plastic tanks

Made entirely of polyethylene – corrosion-free, low-maintenance and lighter than steel. Swimer TECA-Tank and Pressol Fuelstation for 1,500 to 10,000 litres.

Steel large systems

Seppeler KA systems in steel for 3,000 to 10,000 litres – a rugged long-term solution for trade, mid-sized businesses and industry. Analogue flow meter as standard.

Fuel terminal or meter?

Simple refuelling without monitoring: a litre meter is enough. For several drivers, vehicles or cost centres, a digital flow meter or an optional fuel terminal (Kingspan) is the better choice.

⚖ Legal guide

Legal requirements
for farm fuel stations

AwSV, DIBt approval, inspection duties & permits – our guide explains all the key regulations for installing your farm fuel station. With FAQs and practical examples.

Read the guide Reading time approx. 7 min
AwSV
Permit
DIBt
Approval
WGK 2
Diesel
§ 62
Specialist firm
HDPE / sheet steel · compact systems

Comparison HDPE/sheet-steel systems – 1,000 to 2,000 litres

Brands: Roth Schütz Dehoust
Feature UNI Starter Package
Roth · 1,000 L
Uni Plus W85
Roth · 1,000 L
Uni Premium
Roth · 1,000 L
System 1000
Roth · 1,000 L
System 1500
Roth · 1,500 L
2000 Complete
Roth · 2,000 L
Starter Package Horn
Schütz · 1,000 L
Plus W85
Schütz · 1,000 L
Profi – Horn
Schütz · 1,000 L
Plus W85-TecSonic
Schütz · 1,000 L
HDT-TECPUMP 600 VT
Schütz · 1,000 L
Premium Horn
Schütz · 1,000 L
Basic Dehoust
Dehoust · 1,000 L
Profi Dehoust
Dehoust · 1,000 L
Complete System with Filter
Dehoust · 1,000 L
Tank Management CUBE MC
Dehoust · 1,000 L
Brand (tank) RothRothRothRothRothRoth SchützSchützSchützSchützSchützSchütz DehoustDehoustDehoustDehoust
Capacity 1.000 L 1.000 L 1.000 L 1.000 L 1.500 L 2.000 L 1.000 L 1.000 L 1.000 L 1.000 L 1.000 L 1.000 L 1.000 L 1.000 L 1.000 L 1.000 L
Tank material HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel HDPE/steel
Dimensions (L×W×H) 1280×760×1420mm 1280×760×1420mm 1280×760×1420mm 1280×800×1470mm 1640×800×1910mm 2×1100×700×1600 1135×757×1625mm 1135×757×1625mm 1135×757×1625mm 1135×757×1625mm 1135×757×1625mm 1135×757×1625mm 1100×700×1600 1100×700×1600 1100×700×1600 1100×700×1600
Double-walled
Approval DIBt DIBt DIBt DIBt + transport DIBt + transport DIBt DIBt + transport DIBt + transport DIBt + transport DIBt + transport DIBt + transport DIBt + transport DIBt DIBt DIBt DIBt
Integrated flow meter optional optional ✔ Analogue Analogue/Digital Analogue/Digital ✔ Analogue optional optional ✔ Analogue optional ✔ Analogue ✔ Analogue ✔ Analogue ✔ Digital
Integrated fuel terminal
Analogue level gauge
Digital level gauge optionaloptionaloptional optionaloptionaloptional optionaloptionaloptional ✔ incl. optionaloptional optionaloptionaloptionaloptional
Pump output 32 l/min 68 l/min 56 l/min 56 l/min 56 l/min 56 l/min 32 l/min 68 l/min 56 l/min 68 l/min 56 l/min 56 l/min 68 l/min 56 l/min 56 l/min 70 l/min
Power supply 230V230V230V230V230V230V 230V230V230V230V230V230V 230V230V230V230V
Suitable for large fleets
Recommended use Entry-level model Farm, agriculture Farm, agriculture Farm, agriculture Farm, agriculture Trade, mid-sized business Starter package Farm, agriculture Farm, agriculture Farm, agriculture Farm, agriculture Farm, agriculture Farm, agriculture Farm, agriculture Farm, agriculture Farm, agriculture
To the product View View View View View View View View View View View View View View View View

★ Rows highlighted in yellow = key decision criteria  |  DIBt + transport = storage and transport approval  |  All data as per manufacturer specifications

Large systems · PE plastic & steel

Comparison large systems PE & steel – 1,500 to 10,000 litres

Brands: Swimer Kingspan Pressol Seppeler
Feature TECA-Tank 1500
Swimer · PE
TECA-Tank 2500
Swimer · PE
TECA-Tank 3500
Swimer · PE
TECA-Tank 5000
Swimer · PE
TECA-Tank 10000
Swimer · PE
Fuelmaster 2500
Kingspan · PE
Fuelmaster 5000
Kingspan · PE
Fuelmaster 9000
Kingspan · PE
Fuelstation 1500
Pressol · PE
Fuelstation 2500
Pressol · PE
Fuelstation 5000
Pressol · PE
KA 3000
Seppeler · Steel
KA 5000
Seppeler · Steel
KA 10000
Seppeler · Steel
Brand (tank) SwimerSwimerSwimerSwimerSwimer KingspanKingspanKingspan PressolPressolPressol SeppelerSeppelerSeppeler
Capacity 1.500 L 2.500 L 3.500 L 5.000 L 10.000 L 2.500 L 5.000 L 9.000 L 1.500 L 2.500 L 5.000 L 3.000 L 5.000 L 10.000 L
Tank material PEPE PEPEPE PEPEPE PEPEPE SteelSteelSteel
Dimensions (H×W×D) 1950×1358mm 1990×1708mm 2100×2360×3100mm 2060×2318mm 2750×2550×3300mm 246×146×185cm 2850×2230×2340mm 3280×2480×2950mm 1720×1240×2400 1860×1460×2400 2400×2000×2400 2750×1250×1700mm 4350×1250×1700mm 6800×1400×1900mm
Double-walled
Approval DIBtDIBt DIBtDIBtDIBt DIBtDIBtDIBt DIBtDIBtDIBt DIBtDIBtDIBt
Integrated flow meter ✔ Digital ✔ Digital ✔ Digital ✔ Digital ✔ Digital Analogue/Digital Analogue/Digital Analogue/Digital ✔ Analogue ✔ Analogue ✔ Analogue ✔ Analogue ✔ Analogue ✔ Analogue
Integrated fuel terminal optional optional optional
Analogue level gauge
Digital level gauge optional optional
Pump output 55 l/min 55 l/min 68 l/min 68 l/min 68 l/min 72 l/min 72 l/min 72 l/min 65 l/min 65 l/min 65 l/min 56 l/min 56 l/min 56 l/min
Power supply 230V230V230V230V230V 230V230V230V 230V230V230V 230V230V230V
Suitable for large fleets
Recommended use Trade, mid-sized businessTrade, mid-sized businessTrade, mid-sized business Trade, mid-sized businessTrade, mid-sized business Trade, mid-sized businessTrade, mid-sized businessTrade, mid-sized business Trade, mid-sized businessTrade, mid-sized businessTrade, mid-sized business Trade, mid-sized businessTrade, mid-sized businessTrade, mid-sized business
To the product View View View View View View View View View View View View View View

★ Yellow = key decision criteria  |  All data as per manufacturer specifications

Which system fits which operation?

🚜

Agriculture & farmyard

For classic farm applications, Roth and Schütz compact systems from 1,000 L are ideal. Double-walled, DIBt-approved and with an optional flow meter for simple litre tracking.

🔄

PE plastic vs. steel

PE tanks (Swimer, Pressol) are corrosion-free and low-maintenance – ideal for damp locations. Steel tanks (Seppeler) are tougher against mechanical stress in continuous industrial use.

🏭

Fleet & large fleet

For multi-user operation with cost control, the Kingspan Fuelmaster with an optional fuel terminal is the best choice. Digital level gauge and flow meter already integrated.

📊

Digital tracking

The Swimer TECA-Tank comes with a digital flow meter as standard. The Pressol Fuelstation provides a digital level gauge. Ideal when consumption analysis matters.

Highest pump output

At 72 l/min, the Kingspan Fuelmaster models offer the highest delivery rate of any large system. For operations that need to refuel many vehicles quickly.

💰

Affordable entry

The Roth UNI Starter Package and Schütz Starter Package Horn are the most affordable options – simple, complete and ready to use straight away for 1,000 litres of diesel storage.

Buying a farm fuel station

A reliable fuel supply right on your own premises is essential for efficiency and flexibility. When you buy a farm fuel station, you streamline your operations, save time by eliminating external fuel stops and keep full control over your fuel costs. A high-quality on-site fuel station ensures that diesel, heating oil or other media are stored safely and in line with the law at all times. Whether you need a small 1,000-litre farm fuel station for modest quantities or a larger capacity of up to 10,000 litres, there is a suitable solution for every requirement to integrate the storage tank safely and efficiently.

Farm fuel stations for agriculture

Agricultural operations have particular requirements: the system must be rugged enough for outdoor installation, handle diesel and HVO100, and ideally need no separate bund. Double-walled HDPE/sheet-steel systems with DIBt approval meet exactly these conditions – they are permit-free up to 1,000 litres and are delivered and installed directly by us as a WHG-compliant specialist company.

Difference between a farm fuel station and a storage tank

Many people wonder whether a farm fuel station and a conventional storage tank are the same thing. In principle, a double-walled storage tank serves primarily to store liquids such as diesel or heating oil safely. A farm fuel station, by contrast, is a functionally extended version: it consists of the 1,000-litre (or larger) storage tank plus an integrated dispensing unit. So when you buy a farm fuel station, you get a complete system solution that lets you refuel your vehicles directly at the on-site station rather than merely storing the fuel.

Choosing the right farm fuel station and what to consider before buying

Choosing the right system depends on your daily demand and the space available. For small operations, a compact 1,000-litre farm fuel station is often the most economical solution. If you need greater range for large agricultural machinery, however, a 2,000-litre farm fuel station or a larger storage tank of up to 10,000 litres is advisable. When you buy a farm fuel station, always take daily consumption as the basis, so you can plan delivery intervals optimally and use the station efficiently.

It is also essential to make sure it is a double-walled storage tank, in order to comply with statutory environmental protection requirements. The pump of your farm fuel station should also be matched to the required delivery rate. Before ordering, check exactly where it will stand – the ground must be load-bearing and level. A high-quality storage tank also offers advantages in durability and ease of maintenance, which protects your investment.

Advantages of your own farm fuel station

The decision to install a farm fuel station on your premises brings measurable advantages. First, you gain maximum flexibility, as you are no longer dependent on public filling stations when you use a farm fuel station of, say, 1,000 L or a larger model. Second, an on-site fuel station lets you buy larger quantities of fuel at more favourable terms. Not least, you minimise machine downtime, which improves the efficiency of your entire fleet when you buy a farm fuel station.

Above all, deciding on your own farm fuel station means greater independence in day-to-day operations. By choosing the right model, you ensure your vehicles and machines are ready to go at all times. When comparing the storage tank models, pay particular attention to pump output and additional equipment features such as level indicators or nozzle holders. Invest in quality and safety when you buy a farm fuel station, so your double-walled storage tank serves you reliably for many years.

Frequently asked questions about farm fuel stations

HDPE/sheet-steel systems (Table 1) combine an HDPE inner tank with a sheet-steel outer shell – compact, up to 2,000 litres, ideal for farm and agricultural use. PE plastic systems (Table 2) are made entirely of polyethylene, corrosion-free and designed for 1,500–10,000 litres in trade and industry.
The Schütz models (Starter Package Horn, Plus W85, Profi and others) carry, in addition to DIBt storage approval, a transport approval – these tanks may be used mobile on vehicles. Roth and Dehoust models are approved purely for stationary operation.
In Table 1, the Schütz Plus W85-TecSonic is the only model with a digital level gauge as standard. In Table 2, the Swimer TECA-Tank 10000 and the entire Pressol Fuelstation range (1500–5000 L) have a digital level gauge as standard. On the Kingspan Fuelmaster 5000 and 9000 it can be added as an option.
In Table 1, only the Dehoust Tank Management CUBE MC has an integrated fuel terminal. In Table 2, the Kingspan Fuelmaster 2500, 5000 and 9000 offer an optional fuel terminal for fleet management with access control.
Compact systems up to 2,000 L deliver 32–68 l/min – enough for 1–5 vehicles a day. Large systems offer 55–72 l/min. The highest throughput at 72 l/min is achieved by the Kingspan Fuelmaster models. Seppeler KA systems run at 56 l/min and suit continuous operation.
All models come with DIBt storage approval. Tanks up to 1,000 litres are generally permit-free (depending on the federal state). For tanks over 1,000 litres, notification to the local water authority is required; from 10,000 litres, a formal permit is often required. Your local district authority can advise on the rules in your area.
When you buy a farm fuel station, you benefit from time savings, lower fuel prices when buying in larger quantities, and independence from opening hours.
A farm fuel station must stand on a suitable, level surface. You should also check the local fire-safety and environmental protection regulations for storing diesel or heating oil.
A double-walled storage tank is the safest option for a farm fuel station, as the second wall acts as a safety vessel and detects leaks immediately, ensuring protection of soil and groundwater. A leak probe is fitted between the walls. This is a float that rises when liquid enters, so the probe shows red.
For agricultural operations, double-walled compact systems from 1,000 to 2,000 litres are the most common choice – e.g. the Roth UNI Plus W85, Schütz Profi Horn or Dehoust Profi. All with DIBt approval, so no separate bund is needed. For larger farms with several tractors and machines, PE large systems from 2,500 litres (Swimer, Kingspan) are recommended. As a WHG-certified specialist company under § 62 AwSV, we deliver and install the system in full compliance directly on your premises.

Still unsure? We'll advise you free of charge!

Our experts will help you find the right farm fuel station for your operation – from 1,000 to 10,000 litres.

Call +49 36071 924340 View all farm fuel stations
