Diesel Pump Cube 70 M 230V PIUSI 🚜

PIUSI CUBE 70 – High-Performance Diesel Dispensing Unit for Professional Applications

The PIUSI CUBE 70 is a robust and high-performance diesel dispensing unit designed for professional self-consumption. With a flow rate of up to 70 liters per minute, the CUBE 70 is ideally suited for workshops, construction depots, agricultural operations, and fleets with increased diesel demand.

✔ Advantages of the PIUSI CUBE 70

• High flow rate up to 70 l/min for rapid refueling
• Robust, compact design for wall or tank mounting
• Self-priming rotary vane pump with integrated bypass
• Mechanical oscillating disk meter for reliable volume measurement
• Automatic nozzle with nozzle holder and start/stop lever
• Powerful electric motor with thermal overload protection
• Protection class IP55 – suitable for indoor and outdoor use

⚙ Technical Core Data (CUBE 70 Series)

• Flow rate: up to 70 l/min
• Measurement accuracy: ±1 %
• Medium: Diesel (also suitable for biodiesel)
• Pump: PIUSI Panther rotary vane pump
• Meter: Mechanical oscillating disk meter (K33)
• Nozzle: Automatic nozzle
• Protection class: IP55
• Operating mode: Intermittent operation (30 min ON / 30 min OFF)

🔁 Variants of the PIUSI CUBE 70 (Child Items)

The PIUSI CUBE 70 is available in several variants with technical differences. Selection is made via the variant selection of this parent item:

• 🔌 230 V AC – for stationary applications on yard tanks or storage tanks
• 🔋 24 V DC – for mobile applications or vehicle use
• 🛢️ With or without integrated diesel filter 30 µ
• 📏 4m dispensing hose (6m dispensing hose for the variant with filter)
• Meter mechanical roller counter K33 or roller counter K44 with pulse emitter

All variants are based on the same powerful CUBE-70 base platform.

Scope of Delivery (variant-dependent)

• PIUSI CUBE 70 dispensing unit
• Automatic nozzle
• 4m supply hose (6m hose for the variant with filter)
• Mechanical diesel meter
• Nozzle holder with start/stop function
• Mounting materials
• User manual

Typical Areas of Application

• Yard and operational fuel stations
• Construction and municipal depots
• Agriculture and forestry
• Workshops and service operations
• Fleets with high throughput

✅ Conclusion

The PIUSI CUBE 70 is the ideal solution for users who require a high-performance, compact, and reliable diesel dispensing unit. As a parent item, it offers maximum overview – simply choose the appropriate variant via the selection function.
