GFC-B Gas Cylinder Container – Without Partition-RAL 2000 (Yellow Orange)-M2
GFC-B-M2 Gas Cylinder Container – Secure Outdoor Storage for Gas Cylinders
Technical Specifications
The GFC-B Gas Cylinder Container is a specially designed solution for the secure outdoor storage of gas cylinders. It is distinguished by its robust features:
- Fire-resistant walls and roof (F90 according to DIN 4102)
- Lockable swing gate for enhanced protection
- Maximum storage capacity: Up to 40 gas cylinders (Ø 230 mm)
Product Features:
✔ Complies with TRGS 510 standards – Secure outdoor storage of gas cylinders
✔ Fire-resistant walls and roof (F90) – According to DIN 4102
✔ Lockable wire mesh swing gate – For protection and ventilation
✔ Sturdy checker plate floor – Prepared for floor anchoring
✔ Optionally available with fire-resistant partition (F90) – Additional protection
✔ Customizable – Choice of 6 different RAL colors
Available Variants:
The GFC-B product line offers various models to meet different needs. Details are as follows:
- Model: GFC-B M2
- Dimensions (LxWxH): 2125 x 1610 x 2265 mm
- Max. number of gas cylinders (Ø 230 mm): 40
- Weight: 683 kg
- With partition (GFC-B/W): ✅ (35 cylinders)
Colors:
- RAL 2000 (Yellow Orange)
- RAL 3000 (Flame Red)
- RAL 5012 (Light Blue)
- RAL 6011 (Reseda Green)
- RAL 7005 (Mouse Grey)
- RAL 9002 (Grey White)
Accessories & Extensions:
🔹 Holder for upright gas cylinders – With chain securing for additional safety
🔹 Gas cylinder rack GFG – Space-saving storage for up to 11 kg gas cylinders, galvanized, stackable twice
Applications:
✅ Industry & Craft – Secure storage of technical and medical gases
✅ Construction & Logistics – Protection and organization for gas cylinders on construction sites
✅ Fire & Rescue Services – Proper storage of breathing gas cylinders
✅ Agriculture & Trade – Secure outdoor storage for propane and other gas cylinders
With the GFC-B Gas Cylinder Container, you receive a reliable, secure, and robust solution for storing gas cylinders – customizable in size, color, and equipment!
Login
Zubehör
- For gas cylinder containers
- With chain security
- Material: Hot-dip galvanized
- For cylinder diameter: 230 mm
Delivery time: 4-6 Wochen
- For gas cylinders up to 11 kg
- Hot-dip galvanized
- Space-saving & stackable
- Delivered disassembled
Delivery time: 4-6 Wochen
